A-A-55600 Bearings, Roller, Cylindrical, Single Row Of Rollers, Two Roller Retaining Ribs On Inner Ring, Two Roller Retaining Ribs On Outer Ring, Two Direction LocatingThis commercial item description \(CID\) covers the requirements for cylindrical roller bearings, single row of rollers, two roller retaining ribs on inner ring, two roller retaining ribs on outer ring, two direction locating.

Pages 1 - 2 - 3 - 4 - 5


A-A-55600B
TABLE I. Dimensional requirements - Continued.
Recommended
R
shoulder diameter
Shaft &
housing
B
C
Load rating
fillet radius
Shaft
Housing
Overall
A
Outside
(lbs.)
(mm)
(mm)
(mm)
diameter
width
Interchangeable
Dash
Bore
Max.
Min.
Max.
Dynamic
Static
no.
(mm)
(mm)
(mm)
specification
29
90
190
43
0.100
4.25
6.73
38,000
29,600
MS19079-29
30
95
200
45
0.100
4.54
7.09
41,000
34,500
MS19079-30
31
100
215
47
0.100
4.83
7.62
47,600
40,200
MS19079-31
B
A
R
C
R
FIGURE 1. Dimensions.
3.2 Cage. The cage shall be one of the coded options in table II (see 7.3(c)).
TABLE II. Cage materials.
Cage code
Material type
A
Manufacturer's standard
B
Brass
M
Machined brass
N
Non-metallic
J
Steel
3
