A-A-55600B
7. NOTES
7.1 Part or identification number (PIN). The following PIN procedure is for government
purposes and does not constitute a requirement for the contractor.
AA55600 - 10 J C3 R
Example of reference part number:
Snap ring: "R" (if required)
Radial internal clearance: see table III
Cage material: see table II
Dash number: see table I
CID number
AA55600-10JC3R indicates: bore diameter 40 mm, outside diameter 80 mm, overall width 18 mm;
steel cage; greater than normal radial internal clearance; with snap ring.
7.2 Sources of documents.
7.2.1 ABMA standards. Copies of ABMA standards may be obtained from the American
Bearing Manufacturers Association, 2025 M Street NW, Suite 800, Washington, DC 20036.
Electronic copies of ABMA standards may be obtained from https://www.abma-dc.org/.
7.2.2 ASTM standards. Copies of ASTM standards may be obtained from ASTM International,
100 Barr Harbor Drive, P.O. Box C700, West Conshohocken, PA 19428-2959. Electronic
copies of ASTM standards may be obtained from https://www.astm.org/.
7.2.3 SAE standards. Copies of SAE standards may be obtained from SAE International,
400 Commonwealth Drive, Warrendale, PA 15096-0001. Electronic copies of SAE standards
may be obtained from https://www.sae.org/.
7.3 Ordering data. The acquisition order should specify the following:
a.
CID document number, revision, and CID PIN.
b.
Bearing size (see 3.1).
c.
Cage material type (see 3.2).
d.
Precision tolerance requirement (see 3.3).
e.
Preservation, packing, and marking requirements (see 6.1).
7.4 Subject term (key word) listing.
brass
cage
chromium-alloy steel
RBEC-1
5
